Plastic Blow Molding Machine Injection Mold Processing Principle





In recent years, the application of plastic blow molding machines and injection molds has become increasingly widespread. Do you know the processing principle of blow molding machine injection molds? Below, HUIWEN Plastics will give you a brief introduction.



During the production process of plastic blow molding machine injection molds, longitudinal thickness uniformity can be controlled by extrusion stability and traction speed. Transverse thickness uniformity of the film usually depends on the manufacturing of the injection mold. To improve the transverse thickness uniformity of the film, an automatic transverse thickness control system needs to be introduced and used in conjunction with production workers. Common control methods include automatic molds and automatic air rings.



Automatic air power is an online real-time control system. The controlled objects are several motors distributed on the air ring. The circuit structure adopts a double air outlet. The upper air outlet is divided into several air outlets around its circumference, while the air volume of the lower air outlet remains constant. Each air outlet is divided into several sections. The pipeline consists of motors, air chambers, valves, etc. The valves are driven by the motor to adjust the opening of the pipeline. The motor drives the valves to move. When the film becomes thinner, the motor moves forward.



The computer compares the signal with the currently set average thickness, calculates based on the trend of thickness deviation, and controls the lateral thickness deviation of the film within the target range by changing the airflow around the air ring. Cooling airflow from the fan is distributed to each air duct, and the opening and closing of the motor-driven valves alters the cooling effect on the film preform at the discharge point of the injection mold, thereby controlling the film thickness.





This is a brief analysis of the injection mold processing principle of plastic blow molding machines by HUIWEN Plastics. HUIWEN Plastic Parts is a one-stop manufacturer specializing in mold design and manufacturing of plastic products. For many years, it has been a professional group enterprise engaged in mold design, manufacturing, and injection molding production. The company focuses on providing customers with integrated solutions from product design, mold manufacturing, injection molding and assembly, to after-sales service. Its products are widely used in household appliance shells and accessories, medical device injection molding parts, cosmetic packaging injection molding parts, and other fields. Welcome to inquire.
