Study to avoid damage to the inner hole of injection molded parts





HUIWEN PLASTIC PARTS The company researches new internal hole release mechanism and mold, including: The first slider is provided with the first active block and the second active block, the first active block is synchronized with the first sliding block, the second active block is arranged in the first sliding block, the first active block is arranged along the first direction of the inclined plane, the second active block is attached to the inclined plane, the second active block is arranged with the convex platform; The second slider is provided with a driving part, the first slider is connected with the second slider, the second slider is provided with a first guide post, the first guide post is inclined along the second direction through the first slider, the driving part is connected with the second active block, the second direction and the first direction are perpendicular to each other. Through the relative sliding between the first slider and the second slider, the driving part drives the second active block to extend out, the second slider slides along the inclined plane and offset, separated from the inner hole of the injection molding parts, and then demolded to avoid damage to the inner hole of the injection molding parts, improve the production stability, improve the quality of the injection molding parts.
