TPU food-grade sealing rings, TPU medical-grade sealing rings, and TPU industrial sealing rings



TPU food-grade sealing rings, TPU medical-grade sealing rings, and TPU industrial sealing rings, as representative sealing products made of thermoplastic polyurethane, occupy an important position in key fields such as food processing, medical and health care, and industrial manufacturing due to their excellent elasticity, environmental adaptability, and processability. Although all three are derived from TPU material, their different requirements for safety, working condition tolerance, and compliance in different application scenarios have led to their respective independent technical standards and production logics. This article will systematically analyze the core characteristics of these three types of sealing rings from the perspectives of material fundamentals, application scenario adaptation, technological trends, and selection points, providing professional reference for practical production applications and selection.



I. Core Characteristics of TPU Material and Adaptation to Industry Standards



1. Core Basic Performance



As a linear elastomer, TPU possesses excellent elastic recovery and tear resistance. Its Shore hardness covers the commonly used sealing range, and its operating temperature range is -40℃ to 120℃. It is suitable for most conventional and mid-to-high-end working conditions. It exhibits outstanding chemical stability and good resistance to common media (water, grease, weak acids and alkalis).



2. Specific Standard Requirements for Different Application Scenarios



Food-grade application: Must comply with FDA 21 CFR Part 177.2600, GB 4806.10, and other food contact material standards. The material must be odorless, have no harmful substance leaching, and heavy metal content must meet safety limits.



Medical application: Must comply with ISO 10993 biocompatibility standards, meeting cytotoxicity and sensitization requirements, and possess sterilization compatibility (suitable for high-temperature steam and ethylene oxide sterilization).



Industrial application: Must meet GB/T 3452.1-2005 General Standard for Seals, with wear resistance and oil resistance suitable for industrial media environments.



II. Technical Requirements and Production Key Points for TPU Sealing Rings in Three Major Scenarios



1. Food-Grade TPU Sealing Rings



Material Formulation: Uses food-contact grade TPU granules, adds non-migrating additives, avoids heavy metal stabilizers, and ensures material purity.



Production Process: Employs a clean injection molding environment, with strict mold precision control to prevent secondary contamination during molding, ensuring product cleanliness.



Core Application Scenarios: Food filling equipment, drinking water pipelines, beverage machinery, etc., suitable for normal temperature and low-pressure sealing requirements.



2. Medical-Grade TPU Sealing Rings



Material Formulation: Uses medical-grade aliphatic TPU, free of harmful additives, meets biocompatibility standards, and satisfies human contact safety requirements.



Production Process: Produced entirely in a GMP-standard workshop, molds undergo special treatment, and post-molding cleaning eliminates particulate residue.



Core Application Scenarios: Syringes, medical catheters, hemodialysis equipment, etc., emphasizing sealing reliability and biosafety.



3. Industrial TPU Sealing Rings



Material Formulation: Wear-resistant and temperature-resistant modified components can be added according to working conditions. For oil-medium environments, polyester-based TPU with superior oil resistance is selected.



Manufacturing Process: Precision injection molding is used to ensure product dimensional stability and structural integrity, adapting to the installation and usage requirements of industrial equipment.



Core Application Scenarios: Hydraulic systems, automotive transmission components, industrial pumps and valves, etc., resistant to medium-high pressure and dynamic sealing conditions.

III. Technological Development Trends and Application Upgrade Directions



1. Material Modification and Upgrade



The mainstream industry trend focuses on functional modification. Food-grade TPU incorporates natural antibacterial components to improve safety levels; medical-grade TPU is developing biodegradable materials to meet environmental protection and clinical needs; industrial TPU utilizes composite material technology to improve temperature and wear resistance limits, adapting to more demanding working conditions.



2. Molding Process Optimization



Customized production has become an important direction. Small-batch medical sealing rings utilize 3D printing technology for high-precision molding, while large-batch industrial products improve structural stability and installation adaptability through processes such as two-color injection molding, balancing efficiency and quality.



3. Quality Control Upgrade



Online testing technology is widely used. Food-grade and medical products use visual inspection to control dimensions and cleanliness, while industrial products utilize sealing performance testing equipment to monitor reliability in real time, ensuring stable product quality.



IV. Selection and Usage Precautions



1. Scenario Matching Principle



Select TPU type based on media characteristics: Polyether TPU is preferred for food and medical scenarios due to its superior hydrolysis resistance; polyester TPU is selected for industrial oil media scenarios because its oil resistance better meets requirements.



2. Installation and Maintenance



Avoid sharp edges that could damage the sealing ring surface during installation. Food-grade products require regular cleaning according to specifications. Medical products must be replaced strictly according to the sterilization cycle. Industrial products should avoid direct contact with highly corrosive media to extend their service life.



The core development of TPU food-grade, TPU medical-grade, and TPU industrial-grade sealing rings lies in achieving precise application-specific adaptation based on the inherent advantages of the material. From standard compliance to process optimization, from functional upgrades to quality control, these three product categories consistently iterate around the core requirements of "safety, reliability, and compatibility." In the future, with the deep integration of materials technology and intelligent manufacturing, TPU sealing rings will break through application boundaries in more niche scenarios, providing more efficient and precise solutions for sealing systems across various industries, thus contributing to high-quality industrial development.
