With the rapid development of the food delivery economy and the pre-prepared food industry, and the deepening implementation of environmental protection policies, the demand for lightweight, efficient, safe, and compliant packaging products in the food packaging industry continues to rise. Thin-wall injection molds, with their core advantages such as short molding cycles, high material utilization, and low production costs, have become core production equipment for food packaging such as fast food boxes, food storage containers, and cup lids. By precisely controlling the wall thickness (typically within the range of 0.2-1.5mm), they achieve a significant reduction in material waste of 15%-30% while ensuring packaging strength and sealing, aligning with the green and efficient development direction of the food packaging industry. Currently, the application of thin-wall injection molds in the food packaging field accounts for more than 60% of the total number of plastic food container molds, and continues to expand at an average annual growth rate of 8.5%, becoming a key support for driving the upgrading of the food packaging industry.
I. Core Application Scenarios of Thin-Wall Injection Molds in Food Packaging
(I) Production of Disposable Food Containers
Disposable fast food boxes, milk tea cups, and takeout trays are the main application carriers of thin-wall injection molds. These types of packaging need to meet the demands of high-frequency, high-volume production. Thin-wall injection molds, through multi-cavity designs (commonly 16-cavity, 32-cavity, and 64-cavity structures), can compress the molding cycle of a single product to 10-25 seconds, increasing daily production capacity by more than 40% compared to traditional molds. For commonly used food-grade materials such as PP and PS, the molds optimize the runner layout and cooling system to ensure that the wall thickness uniformity error is controlled within ±0.05mm, avoiding insufficient load-bearing capacity or microwave heating deformation problems caused by excessively thin areas.
(II) Manufacturing of Reusable Food Packaging
Reusable packaging such as food storage containers and storage jars require higher precision and durability from the molds. Thin-walled injection molds employ a mirror-polished finish (surface roughness Ra≤0.02μm), coupled with a precision guiding mechanism, to ensure that the dimensional tolerance of the sealing groove is controlled within ±0.01mm, meeting the sealing performance requirements of repeated opening and closing. For biodegradable materials such as PLA and PBAT, the molds address the issues of poor flowability and shrinkage during molding of bio-based materials by adjusting the hot runner temperature profile and gate structure, promoting the large-scale production of environmentally friendly packaging.
(III) Special Functional Food Packaging Molding
For products such as vacuum packaging trays for ready-to-eat foods and pre-prepared dishes, and microwave-safe boxes, thin-walled injection molds need to integrate special functional structures. In-mold insert technology is used to achieve uniform adhesion of the anti-fog coating, or a flow channel structure is designed to improve microwave heating efficiency. These molds require spline testing to verify the structural rationality, ensuring that the product remains free of deformation and odor even under extreme conditions ranging from -20℃ freezing to 120℃ heating.
II. Core Contents of Spline Testing for Thin-Walled Injection Molds for Food Packaging
(I) Design Requirements for Spline Testing Molds
The spline testing mold must accurately simulate the core parameters of the mass production mold, including key structures such as runner dimensions, gate type, and cooling water channel layout. The mold cavity uses standard spline dimensions (commonly 120mm×15mm×1mm standard splines), and multiple adjustable parameter interfaces are reserved to flexibly adjust process parameters such as hot runner temperature (range 160-240℃) and injection pressure (80-150MPa). The mold must be equipped with temperature and pressure sensors to collect key data during the molding process in real time, providing a basis for mass production process optimization.
(II) Key Test Items and Judgment Criteria
Wall Thickness Uniformity Test: The wall thickness of different areas of the spline is measured using a laser thickness gauge. The error must be ≤±0.03mm to ensure uniform stress distribution in mass-produced products.
Mechanical Performance Verification: The tensile strength (≥25MPa for PP, ≥18MPa for PLA) and elongation at break of the test specimens are measured to prevent damage to the packaging during transportation.
Food Contact Safety Testing: Migration detection verifies the release of heavy metals and volatile organic compounds from the specimens, ensuring compliance with GB 4806.7-2023 standards.
Molding Stability Testing: Continuous production of 5000 specimens must maintain a defect rate below 0.3% to ensure the long-term reliability of the mold.
(III) Mass Production Application of Test Results
The specimen test data directly guides the optimization of parameters for mass production molds. For example, adjusting the runner diameter based on melt flow rate test results, or optimizing the water channel layout based on cooling uniformity data. For defects such as shrinkage and flash found during testing, adjusting the gate position or adding venting channels can reduce the mass production defect rate by more than 60%. Spline testing molds can also be used for new material compatibility verification, shortening the R&D cycle of new packaging materials such as biodegradable materials by 30%-40%.
III. Adaptation Principles and Technological Trends of Thin-Wall Injection Molds
(I) Core Adaptation Principles
Material Adaptation: Select mold steel and hot runner system according to the characteristics of the packaging material. P20 pre-hardened steel is suitable for general-purpose materials such as PP and PS, while S136 corrosion-resistant steel is preferred for biodegradable materials.
Structural Adaptation: Multi-cavity parallel design is adopted for rigid packaging (such as lunch boxes), and the demolding mechanism is optimized for flexible packaging (such as cup lids) to avoid product deformation.
Production Capacity Adaptation: 16-32 cavity molds are used for small and medium batch production, while 64-128 cavity stacked molds are suitable for large-volume orders, balancing production capacity and cost.
(II) Current Technological Development Trends
Intelligent Integration: Molds are equipped with industrial internet modules to achieve real-time monitoring of molding parameters and remote fault diagnosis. The equipment networking rate of leading companies has reached 68.4%.
Green Upgrade: Research and development of specialized molds for biodegradable materials has accelerated, with related technology patents increasing by 36% year-on-year in 2024, and mold lifespan extended to over 800,000 cycles.
Precision Enhancement: The widespread adoption of five-axis linkage machining technology has led to mold precision evolving towards ±0.005mm, meeting the aesthetic and functional requirements of high-end food packaging.
(III) Recommendations for Actual Production Adaptation
Manufacturing enterprises should select molds based on packaging type, material characteristics, and production capacity requirements, prioritizing mold solutions validated through spline testing. For high-value-added products, mold flow analysis software (such as Moldflow) can be introduced for preliminary simulation to reduce the number of trial moldings. For mass production, it is recommended to use molds with quick mold change mechanisms to shorten production changeover time. Simultaneously, a regular mold maintenance mechanism should be established, focusing on checking the hot runner system and guiding mechanism to extend mold lifespan.
