II. How to Control Product Quality in Precision Medical Device Injection Molding
1. Raw Material Quality Control
1.1 Material Selection Basis
Material selection for precision medical device injection molding requires a comprehensive consideration of multiple factors to ensure that the material is suitable for its function and operating environment.
Biocompatibility: The material must exhibit no adverse reactions in contact with the human body. For example, implantable devices require highly biocompatible materials to ensure long-term implant safety.
Chemical Stability: The material must be resistant to various chemicals in the medical environment to prevent chemical reactions that could degrade performance and affect device quality.
Physical Properties:
Strength: Select appropriate strength materials based on the stresses to which the device is subjected. For example, surgical instruments must resist breakage, while implantable devices must withstand the stresses of the human body.
Elastic modulus: For materials like vascular stents, the elastic modulus must match that of human blood vessels to ensure support and compliance.
Thermal stability: Consider temperature fluctuations during injection molding and use, such as the requirement for material deformation during high-temperature sterilization.
Medical Injection Molded Parts
1.2 Supplier Screening and Management
Evaluating Key Supplier Metrics
Production Qualifications: Possess legal production licenses and quality certifications.
Quality Control System: Have a comprehensive process to ensure product quality.
Industry Reputation: Select suppliers with a good reputation based on peer reviews.
Establish long-term partnerships.
Stability: Ensure stable raw material supply quantity and delivery time.
Quality Consistency: Provide suppliers with a thorough understanding of requirements to ensure consistent quality.
1.3 Raw Material Inspection Process
Raw materials are subject to comprehensive and rigorous inspection upon arrival.
Appearance Inspection: Observe color, transparency, and the presence of impurities to provide a preliminary assessment of quality.
Physical Property Testing:
Density: Measure and determine composition and the presence of adulteration.
Hardness: Understand wear and compressive properties.
Chemical Property Analysis
Composition Analysis: Confirms that chemical composition meets standards.
Purity Testing: Ensures material purity to ensure device performance and safety.
Testing Properties Related to the Injection Molding Process
Flowability: Affects injection molding; select appropriate flowability materials based on the product.
Shrinkage: Improper control can lead to dimensional deviations in the product; select materials with appropriate shrinkage.
2. Quality Assurance in Mold Design and Manufacturing
2.1 High-Precision Mold Requirements
Precision medical device injection molding requires stringent mold precision, which is crucial to the quality of the molded product.
Cavity Dimensional Accuracy: Requires micron or even nanometer accuracy. Minor deviations can affect product dimensions and medical device performance, such as in molds for micro-components.
Surface Finish: Precision medical molds require a smooth surface to facilitate uniform melt flow, avoid surface defects, and enhance the appearance quality of the product, such as in wearable device housings.
Mold Release Mechanism Design: Carefully designed mold release mechanisms ensure smooth demolding of complex, high-precision products, avoiding damage, such as thin-walled or finely structured injection molded parts.
2.2 Mold Manufacturing Processes and Technologies
Advanced processes and technologies are utilized to meet the high-precision requirements of molds.
Electro-spark Machining: Pulsed discharges between the electrode and the workpiece remove metal, precisely controlling the machining dimensions. This allows for the creation of complex cavities and the precision requirements of molds with specialized shapes.
CNC Machining: CNC programs are used to control machine tool motion, enabling high-precision machining of mold components, ensuring consistent precision and product quality throughout mass production.
Precision Grinding: Fine grinding of key mold areas improves surface finish, facilitates melt flow, and reduces surface defects.
2.3 Mold Verification and Maintenance
Molds must undergo rigorous verification and maintenance before and after production to ensure product quality.
Mold Verification Before Production
Mold Trial: Actual injection molding tests verify mold performance and product quality. Adjustments and improvements are made if any deviations do not meet requirements.
Product Dimension Measurement: Compare the trial mold product to the designed dimensions, analyze the causes of deviations, and take appropriate measures.
Appearance Inspection: Identify any defects in the trial mold product and address them accordingly.
Cleaning: Regularly clean the mold to remove impurities, ensure heat dissipation, and maintain product quality. Lubrication: Lubricates moving parts to reduce wear, extend service life, and ensure smooth demolding.
Worn Part Replacement: Replace worn parts promptly to maintain mold precision and proper operation.
3. Precise Control of Injection Molding Process Parameters
3.1 Key Process Parameters
In the injection molding of precision medical devices, these key process parameters affect product quality.
Injection Pressure: Excessive pressure can cause flash and overflow, while too low pressure can lead to insufficient filling, both of which affect product quality.
Injection Speed: Too high a speed can easily cause air entrainment and bubbles, while too low a speed can increase melt viscosity and make filling difficult.
Dwelling Time: The length of the dwell time affects product density, dimensional accuracy, and internal quality. Too short a time can result in sink marks and other problems, while too long a time can increase internal stress.
Cooling Time: Insufficient cooling time can cause product deformation and dimensional instability. Too long a time can allow for sufficient solidification but can affect production efficiency and performance.
Mold Temperature: The appropriate temperature promotes uniform melt flow. Too high or too low a temperature can affect product molding quality.
3.2 Parameter Optimization and Setting
Precise optimization and setting of process parameters are essential to ensure product quality.
Design of Experiments (e.g., DOE): Systematically vary multiple parameters and observe their impact on product quality to determine the optimal combination.
Simulation Analysis Software (e.g., Moldflow): Use software to simulate the injection molding process, predict problems, and adjust parameters accordingly to optimize quality.
Integrating Product Characteristics and Material Properties: Process parameters must be adjusted accordingly for different product structures and material properties.
3.3 Real-Time Monitoring of Process Parameters
Monitoring Equipment and Technology: Equipped with temperature and pressure sensors and data acquisition systems to monitor parameter status in real time.
Detecting Abnormalities and Adjusting Measures:
Immediately implement adjustment measures if abnormal parameter fluctuations are detected to ensure product quality.
4. Strict Control of the Production Environment
4.1 Cleanliness Requirements
Different Levels of Standards: The injection molding of precision medical devices must meet different cleanroom standards, such as ISO 17442, depending on the device type and production process. The requirements for implantable devices are even higher.
The Importance of a Clean Environment: A clean environment prevents impurities from entering the product, ensuring product biocompatibility and safety. Even minor contamination can have serious consequences.
4.2 Temperature and Humidity Control
Impact on Materials and Molds: Temperature and humidity affect the properties of injection molding materials and mold conditions. High temperatures can cause material deformation and affect product quality; low humidity can easily generate static electricity and attract impurities. Improper temperature and humidity can cause mold deformation and rust.
Control Measures: Use air conditioning and dehumidifiers to control temperature and humidity, and install temperature and humidity sensors for real-time monitoring and timely adjustment.
4.3 Static Electricity Protection
Hazards of Static Electricity: Static electricity discharge can damage electronic components and attract impurities, affecting product functionality, appearance, and biocompatibility.
Protective Measures: Install static eliminators to neutralize static electricity, use anti-static materials for tooling fixtures, and have workers wear anti-static clothing to minimize the effects of static electricity.
5. Quality Inspection and Feedback Mechanism
5.1 Multi-Dimensional Quality Inspection
Appearance Inspection: Visually inspect the surface of injection molded products for defects such as scratches, bubbles, and flow marks, which affect aesthetics and user experience. Careful inspection is required at all stages of production.
Dimensional Measurement: Comparing actual product dimensions with designed dimensions. Minor deviations can cause assembly difficulties or affect performance, requiring precise tools to rigorously measure critical dimensions.
Performance Testing
Mechanical Performance Testing: Testing strength, hardness, and toughness to ensure the safety and reliability of surgical instruments and other devices when subjected to external forces.
Biocompatibility Testing: Evaluating product reactions in the human environment to ensure harmlessness.
Chemical Stability Testing: Testing stability after exposure to chemical substances to ensure the safety and effectiveness of medical devices.
5.2 Online Inspection Technologies
Optical Inspection: Using optical principles to monitor product surfaces and dimensions in real time, quickly identifying problems such as scratches, bubbles, and dimensional deviations.
Ultrasonic Inspection: Analyzing the internal conditions of a product by transmitting and receiving ultrasonic signals to detect defects such as cavities and inclusions. Suitable for complex products.
Advantages of Online Inspection: Real-time detection and feedback of quality issues reduces costs and waste, facilitates production process optimization, and improves efficiency and quality.
5.3 Quality Feedback and Continuous Improvement
Quality Feedback Mechanism: Test results are promptly fed back to relevant departments, such as the production department for appearance issues and the process department for dimensional deviations, enabling each department to resolve the issue.
Continuous Improvement: Based on this feedback, raw materials, molds, and process parameters are optimized, including through material selection, mold repair, and parameter optimization, steadily improving product quality.
