Ten Innovative Breakthroughs in the Injection Molding Process for Zero-Consumable Air Purifier Core Components!

Ten Innovative Breakthroughs in the Injection Molding Process for Zero-Consumable Air Purifier Core Components!



—A Comprehensive Technical Analysis from Mold Design to Material Revolution



I. Submerged Gate Technology: Eliminates Surface Defects and Improves Appearance Quality

Innovation: Utilizing Suzhou Mobi's patented submerged gate design, this design conceals the ejector pins, eliminating ejector marks typically seen on purifier housings during traditional injection molding processes, resulting in a smooth, seamless surface.



Applications: Suitable for high-precision exterior parts such as air purifier housings and air deflectors, meeting consumers' stringent aesthetic requirements.



II. Two-Color Injection Molding and Rapid Cooling System: Efficiently Integrate Complex Structures

Innovation: Drawing on the two-color injection mold technology of Yangzhou Jishan Jintian Optoelectronics, combined with an independent cooling channel design, this system achieves seamless integration of the purifier's internal air ducts and filter components, improving cooling efficiency by 40%.



Benefit: Shortens production cycle time, reduces energy consumption, and solves air leakage issues caused by multi-component assembly.



3. In-Mold Electronics (IME) Process: Integrated Molding of Sensors and Plastic Components

Innovation: Through in-mold embedded electronics, air quality sensors are directly injection-molded into the purifier housing, reducing traditional welding steps and improving component sealing and reliability.



Case Study: A certain brand of purifiers used this technology to reduce sensor failure rates by 60%.



4. Conformal Cooling Water Path Design: Optimizing Heat Dissipation and Energy Consumption

Innovation: A spiral water path and baffle structure precisely control the cooling uniformity of thick-walled components, such as the purifier motor bracket, keeping the temperature differential within ±2°C and reducing the risk of deformation.



Data Support: Experiments show that product yield has increased to 98.5%.



5. High-Gloss Markless Injection Molding Technology: Replacing Secondary Spraying

Innovation: Utilizing rapid thermal cycling high-gloss injection molding technology (patented by Shandong University), the mold temperature is dynamically controlled to above the material's glass transition temperature, achieving a mirror-like finish and avoiding VOC pollution from the spraying process.



Environmental Benefits: Reduces carbon emissions by 30%, complying with EU environmental directives.



6. Servo Drive and AI Parameter Optimization: Dynamically Balancing Energy Consumption and Precision

Innovation: Integrating Shenzhen Lexin Molding's intelligent control system, AI algorithms are used to adjust injection pressure, speed, and hold time in real time, reducing energy consumption by 25% while ensuring component dimensional accuracy of ±0.05mm.



Case Study: A production line achieved an average daily energy saving of 2.3 kWh using this technology.



7. Antibacterial Engineering Plastic Applications: A Double Breakthrough in Materials and Function

Innovation: Using food-grade PC/ABS materials and nano-silver ion modification technology, the purifier filter bracket is endowed with long-lasting antibacterial properties, achieving an antibacterial rate of over 99%.



Test Data: Certified to ISO 22196 standards, with no performance degradation throughout its lifecycle.



8. 3D-Printed Conformal Cooling Molds: Shortening Development Cycles

Innovation: Utilizing metal 3D printing technology to create conformal cooling molds solves the traditional processing challenges of special-shaped air ducts, reducing mold trial cycles from 14 days to 3 days and achieving a mold lifespan exceeding 100,000 cycles.

Cost Comparison: Overall costs are 35% lower than traditional steel molds.



IX. Precision Ejector System Design: Reduces Demolding Damage

Innovation: Optimized ejector pin layout and push plate structure (referring to Changhong Technology's patents) achieve zero-damage demolding in complex structural areas such as the purifier grille, reducing the defect rate from 5% to 0.3%.



Technical Details: Ejector pin spacing ≤ 30mm, diameter ≥ 4mm, with a 2° draft angle design.



X. Bio-based Degradable Materials: The Ultimate Closed Loop for Green Manufacturing

Innovation: Bio-based materials such as PLA are used to injection mold the purifier's removable components. A temperature control process with a precision of ±0.5°C achieves high-strength molding, and the components are naturally degradable after disposal.



Industry Significance: Responding to the "dual carbon" goals and promoting a circular economy model.



Conclusion: The Co-evolution of Technological Iteration and Market Demand

The competition in the zero-consumables air purifier market is essentially a competition in the precision mold manufacturing capabilities of core components. Through continuous innovation in injection mold processing, companies can not only reduce costs and improve quality, but also establish differentiation through green technology and seize the high-end market. In the future, with the deep integration of AI and new materials technology, injection molding will drive the air purification industry towards a smarter and more sustainable direction.
